Dahua WizSense 3 Anti-corrosion 8MP 180° Panoramic IP Camera DAHUA-5487 (TiOC, Duo Splicing)
Dahua WizSense 3 Anti-corrosion 8MP 180° Panoramic IP Camera DAHUA-5487 (TiOC, Duo Splicing)
Dahua
Regular price
746,75 €
Regular price
Sale price
746,75 €
Unit price
/
per
Price excl. VAT · 21% VAT added at checkout
Shipping calculated at checkout.
Couldn't load pickup availability
Dahua WizSense 3 anti-corrosion IP camera with dual sensor (2x4MP) and 180° panoramic image (Duo Splicing) and maximum resolution of 8MP. It incorporates TiOC technology with active deterrence (siren and red/blue light), Smart Dual Light and AcuPick analytics. C5-H and NEMA 4X anti-corrosion casing, designed for coastal and high salinity environments.
Benefits
180° panoramic in 8MP
Dual 2x4MP sensor with Duo Splicing, up to 4320x1944 at 20 fps, no blind spots.
Dual 2x4MP sensor with Duo Splicing, up to 4320x1944 at 20 fps, no blind spots.
TiOC with active deterrence
Siren and red/blue light to deter intruders in real time.
Siren and red/blue light to deter intruders in real time.
Smart Dual Light night vision
30 m IR and 30 m warm light, with 120 dB WDR.
30 m IR and 30 m warm light, with 120 dB WDR.
Advanced intelligence
AcuPick, IVS, SMD 4.0, facial detection and EPTZ.
AcuPick, IVS, SMD 4.0, facial detection and EPTZ.
Corrosion protection for the coast
C5-H and NEMA 4X protection, reliable use up to 2 km from the coast.
C5-H and NEMA 4X protection, reliable use up to 2 km from the coast.
Two-way audio
Dual microphone and dual speaker built-in.
Dual microphone and dual speaker built-in.
Technical specifications
| Type | 180° panoramic anti-corrosion IP, outdoor |
| Sensor | 1/2.7" CMOS, dual 2x4MP sensor |
| Maximum resolution | 8MP (4320x1944) at 20 fps |
| Minimum illumination | 0.003 lux F1.4 (color), 0.0003 lux (B/W), 0 lux with illuminator |
| Smart Dual Light | IR up to 30 m and warm light up to 30 m (4 multi-core lights) |
| Optics | Fixed 2.8 mm, M12 mount, F1.4, fixed iris |
| Field of view | H 180°, V 72° |
| Day / night | Auto (ICR), color and B/W |
| Minimum focus | 0.8 m |
Video
- H.265, H.264/H/B, MJPEG, AI H.264/H.265 and Smart H.264+/H.265+ compression.
- 3 streams: main 4320x1944 (1 to 20 fps), substream 1200x536, third stream 1920x860.
- VBR, CBR and ABR rate control. Bitrate from 6 kbps to 16384 kbps.
- BLC, HLC, real WDR 120 dB, 3D NR, SSA scene adaptation and Defog.
- Privacy mask (8 areas), RoI (4 areas) and digital watermark.
Smart functions
- Xinghan Vision large-scale AI models.
- IVS perimeter protection: intrusion and tripwire with human and vehicle classification, loitering and lingering.
- SMD 4.0.
- AcuPick: search and locate people, animals and vehicles in live and recorded video.
- Full image facial detection with capture, optimization and facial exposure.
- Electronic EPTZ for tracking targets associated with smart alarms.
Active deterrence (TiOC)
- Light warning with red and blue lights. Flashing or steady on from 5s to 30s, high, medium or low frequency.
- Acoustic warning with siren, 11 sound alarms and custom sound import.
- Adjustable volume from 0 to 100 and playback from 1 to 10 times.
Audio, alarms and storage
- Two-way audio with dual microphone and dual speaker. 1 RCA input and 1 output. PCM, G.711a, G.711Mu, G.726 and G.723.
- 1 alarm input and 1 output (dry and wet contact).
- MicroSD up to 512 GB (not included), plus storage on FTP, SFTP and NAS.
Network, protocols and security
- RJ45 10/100/1000 Base-T interface, with SDK and API.
- Protocols IPv4, IPv6, HTTP, TCP, UDP, RTSP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, multicast, SNMP, P2P and more.
- ONVIF Profile S, G, T and M, and CGI. Up to 20 users.
- Smart PSS Lite, DSS, DMSS and DoLynk Care software. iOS and Android mobile client.
- Security: HTTPS, 802.1x, IP/MAC filtering, X.509, Trusted Boot, Trusted Execution, Trusted Upgrade and account lockout.
Power, environmental and physical
| Power supply | 12 VDC (±30%) and PoE+ IEEE 802.3at, with dual power backup. Max consumption 16.1 W (PoE) |
| Temperature | from -40 °C to +60 °C, humidity ≤95% non-condensing |
| Protection | IP67, C5-H anti-corrosion and NEMA 4X (Professional Protection). Reliable use up to 2 km from the coast |
| 3AXIS adjustment | Pan 0° to 360°, tilt -20° to 90°, rotation 0° to 360° |
| Material | Improved anti-corrosion aluminum alloy |
| Dimensions | 183.1 x 99 x 78 mm. Net weight 0.695 kg. Ceiling, wall or pole mounting |
Contents and certifications
Includes: 180° panoramic anti-corrosion IP camera with TiOC, Duo Splicing, active deterrence and fixed optics DAHUA-5487 (DH-IPC-PFW3859SP-A180-E2-AS-PV-0280B-ATC).
Certifications: CE-LVD EN 62368-1, CE-EMC (Directive 2014/30/EU) and NEMA 4X.
Warranty and support
Dahua product distributed by DeProdeCa, with its own technical service (SAT) and advice on selection, installation and configuration. Includes manufacturer's warranty.
